A vertical sump pump is a long-shaft pump used to move wastewater, light sludge, and mixed water from a pit or tank. The pump end works near the liquid, while the motor stays higher, so daily checking is easier and safer. It is often used in workshops, drainage wells, and treatment rooms where water level changes during the day.
This product can handle water with small soft solids when the passage size and impeller are chosen correctly. Its open or semi-open impeller helps reduce blocking, and the vertical layout makes it simple to connect with fixed pipes. This product also fits narrow spaces because it does not need a wide base. When the sump depth, flow rate, and head are matched before ordering, this product can run in a steadier way and need less site adjustment.
Product Parameters
|
Parameter |
Value |
|
Pump Type |
Vertical sump pump |
|
Flow Range |
10-300 m³/h |
|
Head Range |
8-60 m |
|
Power |
1.5-55 kW |
|
Material |
Cast iron, stainless steel or wear resistant alloy |
|
Impeller Type |
Open or semi-open impeller |
|
Shaft Length |
500-2500 mm can be matched to sump depth |
|
Solids Passage |
10-50 mm by model |
|
Installation |
Fixed vertical installation |
|
Application |
Sump drainage, wastewater transfer, pit pumping |
Product Advantages
1. For vertical sump pump, the motor is kept above the liquid, so inspection is easier.
2. The vertical body saves space beside tanks and pits.
3. Impeller and shaft length can be matched to site depth.
Main Applications
1. Drainage pits in workshops and service rooms.
2. Wastewater tanks before the next treatment step.
3. Small sumps where floor space is limited.
FAQ
Q: Can it run dry for a long time?
A: No. It should keep enough liquid around the pump end.
Q: Can the shaft length be changed?
A: Yes. It should be decided by the real sump depth.
Q: Is it used for clean water only?
A: No. It can move dirty water if the solid size is within the model range.
